Products > Landscape Lighting > 120V Mini Flood Light (CCT)

120V Mini Flood Light (CCT)

Product Category OutdoorOutdoor Product Category CCTCCT

Very wide distribution flood in a small discrete housing: 3 different wattages and variety of mounting solutions, great performance in a small package.

CCT Adjust Mini Flood Lights provide exceptional illumination for architectural, signage and landscape applications.

CCT adjustable with a push of a button 3000K/4000K/5000K.

Find Local Rep

Share this product:
Product Code FL-15-CT FL-30-CT FL-50-CT
Electrical Input Voltage 120V-277V AC
Power Consumption 15W 30W 50W
Specs Colour Temperature 3000/4000/5000K
CRI >80
Lumen Output 3000K: 1725-1950LM 3000K: 3450-3900LM 3000K: 5750-6500LM
4000K: 2025-2250LM 4000K: 4050-4500LM 4000K: 6750-7500LM
5000K: 1875-2100LM 5000K: 3750-4200LM 5000K: 6250-7000LM
Efficacy (LM/W) N/A
Dimmable N/A
Beam Angle 150° x 120° (7H6V)
LED Type SMD3030 (1W)
Life Span 50,000 Hours
Design Dimensions (Inches) 6 5/8 x 8 x 1 3/4” 6 5/8 x 8 x 1 3/4” 7 5/16 x 9 7/16 x 1 15/16”
Dimensions (Milimeters) 168.3 x 204 x 43.7 mm 168.3 x 204 x 43.7 mm 201 x 239 x 49 mm
Finish Black
Material N/A
Operating Temperature *-20 to +50°C
Approved Location Wet
Mounting Via Stake
Warranty 5 year
Approvals cULus listed for wet location
Accessory - Wire guard

MOUNTING ACCESSORIES: FL-WG-15/30/50

Wire guard

Accessory - Glare shield

MOUNTING ACCESSORIES: FL-SH-15/30/50

Glare shield

Accessory - Universal mount bracket For use on poles

MOUNTING ACCESSORIES: FL-ADM-15/30/50

Universal mount bracket For use on poles

Accessory - Yoke mount bracket To use for wall and ground mount

MOUNTING ACCESSORIES: FL-Y-15/30/50

Yoke mount bracket To use for wall and ground mount

Accessory - Trunnion mount bracket To use for wall and ground mount

MOUNTING ACCESSORIES: FL-TR

Trunnion mount bracket To use for wall and ground mount

This product is suitable for the following applications:

  • Architectural lighting
  • Signage
  • Landscape lighting
  • Exterior commercial
