Round/Square – LED Surface Mount Down Lights

LED Surface Mount Down Lights are a low-profile down light intended for ceiling mount applications. They feature driver on board (DOB) technology, with no external driver needed. These flush mount LED ceiling lights mount directly into a 4” junction box. Ideal for general LED lighting in residential and commercial applications.

Product Brochure

Find Local Rep

_{Share this product:}

ROUND	LVLDL-SR-06-XX-WH-L	LVLDL-SR-08-XX-WH-L	LVLDL-SR-10-XX-WH-L	LVLDL-SR-12-XX-WH-L
LED Colour	White
Colour Temperature CCT	3000K / 4000K
Input Voltage	120V
Power Consumption (W)	11	14	17	22
Lumens WW NW	880 900	1000 105	1200 1250	1800 1850
Luminous Efficacy (LPW) WW NW	80 82	71 75	70 73	82 84
Colour Rendering Index	>80
Dimmable	Yes
Life Span (hours)	50,000 hrs
LEDs	Epistar
Appearance Size	6” D x 1” H (152mm D x 25mm H)	8” D x 1” H (203mm D x 25mm H)	10” D x 1” H (254mm D x 25mm H)	12” D x 1” H (305mm D x 25mm H)

SQUARE	LVLDL-SS-06-XX-WH-L	LVLDL-SS-08-XX-WH-L	LVLDL-SS-10-XX-WH-L	LVLDL-SS-12-XX-WH-L
LED Colour	White
Colour Temperature CCT	3000K / 4000K
Input Voltage	120V
Power Consumption (W)	11	14	17	22
Lumens WW NW	880 900	1000 1050	1200 1250	1800 1850
Luminous Efficacy (LPW) WW NW	80 82	71 75	70 73	82 84
Colour Rendering Index	>80
Dimmable	Yes
Life Span (hours)	50,000 hrs
LEDs	Epistar
Appearance Size	6” D x 1” H (152mm D x 25mm H)	8” D x 1” H (203mm D x 25mm H)	10” D x 1” H (254mm D x 25mm H)	12” D x 1” H (305mm D x 25mm H)
