Low Power Indoor (3000K)
This 3000K low-power indoor tape light delivers a refined, smooth, and pixel-free lighting experience, ideal for modern interior applications. Engineered with dense 2219 LED chips mounted on an 8mm wide PCB, it provides uniform brightness and superior colour accuracy, ensuring a consistent 3000K warm white output. Consuming only 4.8W per meter, it is optimized for energy efficiency without compromising performance. With a compact design, it integrates seamlessly into tight spaces such as cabinets, coves, and display lighting.
Designed for reliability, the tape light maintains excellent colour consistency (SDCM<3), backed by a robust CRI 90 rating for high colour rendering, making it suitable for environments demanding precision lighting. Its 140° beam angle ensures smooth light distribution, and the IP40 rating offers protection against dust in indoor settings. A long lifespan of 50,000 hours, coupled with versatile dimming options (PWM, 0-10V, 1-10V), makes this tape light a durable and adaptable solution for various lighting needs.
Tape Selection Chart and Replacement Guide
Compatible Controllers and Remotes:
- 0/1~10V Dimming Controller {CNTRL-0-10V-DIM}
- Rotating CCT Scene Remote {CNTRL-4Z-CCT-RWP-WH / CNTRL-4Z-CCT-RWP-BK}
- 4 Zone CCT Remote {CNTRL-4Z-CCT-RM}
The Low Power Indoor (3000K) replaces the following lighting solutions:
- Low Power Indoor {LTP-XX-3000K-H90-LP}
- Low Power Indoor {LTP-XX-YY-LP}
- High Density, Low Power Indoor (3000K) {LTP-XX-3000K-HD-LP-H90}
Key Features:
- Pixel-Free, Uniform Output: Smooth, continuous 3000K warm white light suitable for refined spaces.
- High Efficiency: Consumes only 4.8W per meter with an efficacy of 110 lumens per watt.
- Precision Lighting: Maintains colour consistency with SDCM<3 and features CRI 90 for accurate colour rendering.
- Compact Design: Slim 8mm wide PCB, 3mm height, for discreet installation.
- Long Lifespan: Up to 50,000 hours of reliable operation, minimizing maintenance costs.
- Customizable: Cuttable at intervals of 2.19 inches (55.5mm) for tailored applications.
- Dimming Compatibility: Supports PWM, 0-10V, and 1-10V dimming systems for adaptable brightness control.
- Robust Build: IP40 rated for indoor environments, ensuring dust protection.
- Approvals and Warranty: Certified with cULus and backed by a 5-year warranty.
The Low Power Indoor 3000K LED Tape Light stands out for its precision-engineered uniformity, energy efficiency, and adaptability. Its slim design, superior colour rendering, and pixel-free light make it an ideal solution for contractors, architects, and specifiers seeking high-performance lighting for detailed indoor applications. Reliable, versatile, and backed by a 5-year warranty, this tape light ensures long-term value and seamless integration into modern interior environments.
SPECIFICATIONS | ||
Product Code | SL-ID-30K-LP-XX-A8 [XX: Length in feet; A: 2219 LED; 8: 8mm PCB] | |
Available in 20 or 100 feet; For 20 feet: SL-ID-30K-LP-20-A8; For 100 feet: SL-ID-30K-LP-100-A8 | ||
Electrical | Input Voltage | 24V DC |
Power Consumption | 1.46W/ft (4.8 W/m) | |
Efficacy | 110Lm/w | |
Specs | Colour Temperature | 3000K |
Lumen Output | 160Lm/ft (528Lm/m) | |
Beam Angle | 140° | |
Dimmable | Yes (PWM / 0-10V / 1-10V) | |
LED | Chip Type | 2219 |
CRI | 90 | |
# per metre | 288 | |
Binning | 1BIN | |
SDCM | <3 | |
Lifespan | 50,000 Hours | |
Design | Dimensions (Inches) | .31” W |
Dimensions (Millimetres) | 8mm W | |
Max Length | 40Ft (12M) | |
Custom Cuttable | 2.19’’ (55.5mm) | |
IP Rating | IP40 | |
Approved Location | Indoor | |
Warranty | 5 Years | |
Approvals | cULus |
SL-ID-W2BC-72
6’ Powerfeed
SL-ID-BWBC-6
6” Jumper
SL-ID-B2BC
Splice
SL-ID-LC
L-shaped Connector
SL-ID-TC
T-shaped Connector
